Venus 33 (IP65)

Characteristic

  • Professional rainproof design system (IP 65), with high-end waterproof connectors and efficient cooling, Heatsink area covers 40% of the laser case area, Venus RGB33,000 performs greatly even under any extreme weather.
  • Brilliant colors with great linear color fading behavior, compact size and low weight design makes it perfect for all indoor and outdoor great events.
  • Build in Pangolin FB4 control interface with network switch for professional control and wiring.
  • Compliance: FDA/CDRH and CE.
  • Warranty: 24 months parts and labor.

Description

Specification:

  • Total laser power:                ≥ 33,000mW
  • R丨G丨B                            9,000 mW 丨12,000 mW 丨12,000 mW
  • Beam divergence:              <1.0mrad(full angle)
  • Modulation:                         100KHz Analog
  • Modulation way:                  linear analog modulation
  • Scanner type:                     PT-A30HP
  • Scanning System:              30Kpps@8°
  • Scan angle:                        45°
  • Signal connector:               Ethernet,ArtNet,FB4-DMX
  • Ingress rating:                    IP65
  • Temperature control:         TEC
  • Operatingtemperature:      -10℃-40℃
  • Dimensions:                      L446×W286×H249mm
  • Weight:                              32kg
  • Power requirements:        100-240V50/60Hz
  • Consumption:                    1200W

Show Effect



DATASHEET

Venus 33W(IP65)
