Venus 5.5

Characteristic

  • Optional to build in Pangolin FB4, controlling via Ethernet, ArtNet, DMX, ILDA or SD card etc.
  • Compact size, low weight system, Low divergence < 1.0 mrad (full angle), great for beams and graphics shows.
  • Compliance: FDA/CDRH and CE.
  • Warranty: 24 months parts and labor.

Description

Specification:

  • Total laser power:                ≥ 5,500mW
  • R丨G丨B                             1,500mW 丨1,800mW 丨2,200mW
  • Beam divergence:               <1.0mrad(full angle)
  • Modulation:                         100KHz Analog
  • Modulation way:                  linear analog modulation
  • Scanner type:                      PT-A40HP
  • Scanning System:               35Kpps@8°
  • Scan angle:                         45°
  • Signal connector:                Ethernet,ArtNet,DMX,ILDA
  • Ingress rating:                     indoor
  • Temperature control:          TEC
  • Operatingtemperature:       -10℃-40℃
  • Dimensions:                        L266×W219×H181mm
  • Weight:                                8.5kg
  • Power requirements:          100-240V50/60Hz
  • Consumption:                     150W

Show Effect


datasheet

VENUS 5.5W
