Starburst RGB 5,5

Characteristic

  • Optional to build in Grating wheel, it gives you 3 amazing grating effects, and one empty slot is used during normal laser display, the grating module is BEYOND connector.
  • Optional to build in Pangolin FB4, controlling via Ethernet, ArtNet, DMX, ILDA or SD card etc.
  • Compact size, low weight system, Low divergence < 1.0 mrad (full angle), great for beams and graphics shows.
  • Compliance: FDA/CDRH and CE.
  • Warranty: 24 months parts and labor.

Description

Specification:

  • Total laser power:                 ≥ 5500mW
  • R丨G丨B mW                      1500丨2000丨2000
  • Beam divergence:                 <1.0mrad(full angle)
  • Modulation:                           100KHz Analog
  • Modulation way:                    linear analog modulation
  • Scanner type:                        PT-A40HP
  • Scanning System:                35Kpps@8°
  • Scan angle:                          45°
  • Signal connector:                  Ethernet,ArtNet,FB4-DMX,ILDA
  • Ingress rating:                       IP20
  • Temperature control:            TEC
  • Operatingtemperature:         -10℃-40℃
  • Dimensions:                         L266×W219×H164mm
  • Weight:                                10kg
  • Power requirements:           100-240V50/60Hz
  • Consumption:                       150W

Show Effect


datasheet

starburst RGB-5.500datasheet
